High-Speed CNC Paper Corner Protector Machine

High-Speed CNC Paper Corner Protector Machine
High-Speed CNC Paper Corner Protector Machine High-Speed CNC Paper Corner Protector Machine High-Speed CNC Paper Corner Protector Machine
Inquiry
Applications

The paper corner protector machine is designed to produce cardboard edge protectors with widths of 25–100 mm and thicknesses of 2–8 mm. These protectors are commonly used to safeguard product corners and prevent damage to boxes during stacking on pallets.

Features
  • Offers multiple model options, including standard cardboard corner protectors and perforated angle board edge protectors with punching or ring-shaped designs for added versatility.
  • Equipped with advanced servo-driven tracking cutting technology, enabling customizable order lengths and enhancing operational flexibility and efficiency.
High-Speed CNC Paper Corner Protector Machine
High-Speed CNC Paper Corner Protector Machine
High-Speed CNC Paper Corner Protector Machine
High-Speed CNC Paper Corner Protector Machine
Technical Parameters
Machine Type GC-40 GC-60 GC2-40 GC2-60

Paper Corner Protector		 Width: 25-100mm
Length: 50-9000mm
Thickness: 2-8mm
Production Speed 0-40m/min 0-60m/min 0-40m/min 0-60m/min
Motor Power 7.5kW+4.3kW 11kW+4.3kW 7.5kW+4.3kW*2 11kW+4.3kW*2
Control Mode CNC

Raw Material		 Surface paper 150g-220g
Core paper 300g-700g
Cutting Mode Servo-controlled tracking for CNC cutting
Number of Operators 1-2
Machine Dimensions (L*W*H) 4700*870*1650mm 7000*870*1650mm 4700*870*1650mm 7000*870*1650mm
Machine Footprint (L*W) 27m*3m 33m*3m 27m*3m 33m*3m
Main Machine Weight 2292kg 3024kg 2292kg 3024kg
Total Weight 4410kg 5142kg 4655kg 5387kg
Motor Speed 1400r/min 1400r/min 1400r/min 1400r/min
